Rental 1920Hz LED Display / Led Wall Screen PH6mm 480x480mm
Rental 1920Hz LED Display / Led Wall Screen PH6mm 480x480mm
Integration Power Supply
Integrated design, power supply and control card are built-in each cabinet.The 220/110V to 5V power supply combines with led strip which can improve the stability of power supply and convenient to power connection.
Save Time And Labor Cost
Simple install structure can be set up very fast which save time and labor cost.
Specifications:
|
LED Lamp Specification |
||||||
|
Color |
Package |
Intensity |
Viewing angle |
Wavelength |
Testing condition |
|
|
Red |
SMD3535 |
800-1100mcd |
120° |
620-625nm |
25℃,20mA |
|
|
Green |
SMD3535 |
1600-2250mcd |
120° |
515-530nm |
25℃,20mA |
|
|
Blue |
SMD3535 |
350-500mcd |
120° |
465-475nm |
25℃,20mA |
|
|
Module Parameter |
||||||
|
Pixel Pitch |
6mm |
|||||
|
Pixel Configuration |
SMD3535 |
|||||
|
Density |
27,778 pixels/sqm |
|||||
|
Module Resolution |
32pixel(L) * 32pixel(H) |
|||||
|
Driving Mode |
Constant current, 1/4 duty |
|||||
|
Module Mask |
Pure black mask---high contrast screen |
|||||
|
LED Cabinet |
||||||
|
Cabinet Material |
Die Cast Aluminum |
|||||
|
Cabinet Weight |
≈12KG |
|||||
|
Electricity Parameter |
||||||
|
Optical Ratings |
||||||
|
Brightness |
≥6,500 cd/sqm |
|||||
|
Viewing Angle |
120°(Horizontal); 120°(Vertical) |
|||||
|
Best Viewing Distance |
≥6m |
|||||
|
Display Color |
4.4 trillion colors |
|||||
|
Brightness Adjustment |
100 grades by software or automatically by sensor |
|||||
|
Operation Power |
AC100-240V 50-60Hz Switchable |
|||||
|
Max. Power Consumption |
850 W/sqm |
|||||
|
Avg. Power Consumption |
280W/qsm |
|||||
|
Control System |
||||||
|
Frame Frequency |
≥60Hz |
|||||
|
Refresh Frequency |
≥1,920Hz |
|||||
|
Input Signal |
Composite Video, S-video, DVI, HDMI, SDI, HD-SDI |
|||||
|
Control Distance |
100m(Ethernet cable); 20KM(optical fiber cable) |
|||||
|
Support VGA Mode |
800*600, 1024*768, 1280*1024, 1600*1200 |
|||||
|
Color Temperature |
5000—9300 adjustable |
|||||
|
Brightness Correction |
Pixel by pixel, module by module, cabinet by cabinet |
|||||
|
Reliability |
||||||
|
Working Temperature |
-20~+60 ºC |
|||||
|
Storage Temperature |
-30~+70 ºC |
|||||
|
Working Humidity |
10%~90% RH |
|||||
|
Lifetime |
100,000 hours |
|||||
|
MTBF |
5000 hours |
|||||
|
Continuous Operating Time |
≥72 hours |
|||||
|
Protection Grade |
IP43 |
|||||
Features:
High-definition visual effect.
High thermal conductivity Alloy cabinet, better heat dissipation
Fan-free design, energy saving, more stable,
140〫 degree wilde view angle
Approved by RoHS certification, Lead-free, enviromental design
Ergonomic handle design, convenient handling
Payment terms:
T/T 30% down payment upon order confirmation and 70% balance in one week before shipment.
Shipment: From Shenzhen, China to unconfirmed by sea/air.
Delivery date: Within 20 working days upon receipt of 30% T/T down payment.
