Stage 3840Hz -1920Hz LED Display HD Led Screen Module 3000-12000K

Basic Properties
Place of Origin: China
Certification: CE, CCC, FCC, ROSH, ISO9001
Trading Properties
Minimum Order Quantity: 1pcs
Price: USD 400-1999 per sqm
Payment Terms: T/T, Western Union
Supply Ability: 1300 square meters per month
Tags

sports led display

led stadium display

led perimeter display
Product Summary
Stage 3840Hz -1920Hz LED Display HD Led Screen Module 3000-12000K Specifications: Pixel Pitch 2mm Pixel Package SMD1010 LED Configuration 1R1G1B Pixel Density 250000 Pixels/㎡ Module Size 128mm x 128mm Module Resolution 64 x 64 dots Suggested Cabinet Size 512mm x 512mm x 70mm Cabinet Resolution 256 x 256 dots Cabinet Material Die-casting Aluminum Alloy Cabinet Weight 3.5 kg/panel Brightness 600-1200 nits Color Temperature 3000-12000K Viewing Angle H-140°/ V-140° Driving Mode 1

Product Details

Highlight:

commercial led display

,

rgb led screen
Pixel Pitch: PH2mm
Encapsulation: SMD2121
Refresh Rate: 1920Hz-3840Hz
Cabinet: Die-casting Aluminum Alloy
Cabinet Size: 512x512mm
View Angle: 140°(Horizontal )/140°(Vertical )
LED Lifespan: 100,000 Hours
Working Voltage: AC 220V/110V S±15% 50-60 HZ
Viewing Distance: 2-60 Meters
Product Description

Stage 3840Hz -1920Hz LED Display HD Led Screen Module 3000-12000K



Specifications:



Pixel Pitch 2mm
Pixel Package SMD1010
LED Configuration 1R1G1B
Pixel Density 250000 Pixels/㎡
Module Size 128mm x 128mm
Module Resolution 64 x 64 dots
Suggested Cabinet Size 512mm x 512mm x 70mm
Cabinet Resolution 256 x 256 dots
Cabinet Material Die-casting Aluminum Alloy
Cabinet Weight 3.5 kg/panel
Brightness 600-1200 nits
Color Temperature 3000-12000K
Viewing Angle H-140°/ V-140°
Driving Mode 1/32
Refresh Rate 1920-3840Hz
Frame Frenquency 60Hz
Grey Level 4096-16384
Number of Color 1 billion
Input Maximum Power 2100 W/㎡
Input Voltage AC220±10%, AC110 ±10%
Input Frequency 50-60Hz
External Interface S-video, VGA, DVI, SDI, CVBS, YPrPb, HDMI, etc
IP Rating IP43


Using LED modular cabinet, it allows you to increase your LED screens' work-life thanks to their high reliability and advanced features. Light weight, slim and seamless installation, LED display cabinet with conveniences over the conventional fixed led screen, it makes things easier for stack or hanging installation without any tools.
Stage 3840Hz -1920Hz LED Display HD Led Screen Module 3000-12000K 0Stage 3840Hz -1920Hz LED Display HD Led Screen Module 3000-12000K 1


1. After-sales service:



1) Service principles: response in time, solve problems as soon as possible, and ensure the use.

2) Service period: In the Maintenance period of the LED screen body, free of all maintenance charges; After the Maintenance period, only charge the material costs fees free of manual work fees.

3) Service scope: If the users find any problem that cannot be solved, please contact with our company, we can response in 24 hours. In order to shorten the maintenance time, Our Company will deploy some spare parts such as power and chips, etc.

4) Under normal use and storage, Our Company will be responsible for the equipment.



2. Pre-sales service:



1) Our company can arrange professionals to conduct site installation and debugging in strict accordance with the requirements of the schemes and the original manual. If there is any special requirement, it is necessary to make changes of part installation scheme, we will coordinate with users. Our company can ensure the consistence of completion time and contracted time. Any problems caused by natural factors or man-made, we will discuss with the client to find solutions.

2) Our company can train users based on the manual. The training includes system use, system maintenance, and equipment protection.
