Ultra Thin Modular Hire Led Screen SMD3528 1R1G1B 16x16 Led Matrix Display
Basic Properties
Place of Origin:
China
Certification:
CE, CCC, FCC, ROSH, ISO9001
Trading Properties
Minimum Order Quantity:
1pcs
Price:
USD 400-1999 per sqm
Payment Terms:
T/T, Western Union
Supply Ability:
1300 square meters per month
Product Summary
Ultra Thin Modular Hire Led Screen SMD3528 1R1G1B 16x16 Led Matrix Display Specifications: Pixel Pitch 4.81mm Pixel Package SMD3528 LED Configuration 1R1G1B Pixel Density 43222Pixels/㎡ Module Size 250mm x 250mm Module Resolution 52 x 52 dots Suggested Cabinet Size 500mm x 500mm Cabinet Resolution 104x 104 dots Cabinet Material Aluminum Cabinet Weight 9kg/panel Brightness ＞1200 nits Color Temperature 3000-12000K Viewing Angle H-140°/ V-140° Refresh Rate 960-2880Hz Frame
Product Details
Highlight:
modular led display
,led video screen hire
Product Name:
Rental LED Displays
Cabinet Material:
Die-casting Aluminum
Viewing Distance:
Over 4.81m
Cabinet Size:
500 X 500 Mm
LED Package:
SMD3528
Cabinet Weight:
9 Kg/panel
Color:
Full Color
Product Description
Ultra Thin Modular Hire Led Screen SMD3528 1R1G1B 16x16 Led Matrix Display
Specifications:
| Pixel Pitch | 4.81mm |
| Pixel Package | SMD3528 |
| LED Configuration | 1R1G1B |
| Pixel Density | 43222Pixels/㎡ |
| Module Size | 250mm x 250mm |
| Module Resolution | 52 x 52 dots |
| Suggested Cabinet Size | 500mm x 500mm |
| Cabinet Resolution | 104x 104 dots |
| Cabinet Material | Aluminum |
| Cabinet Weight | 9kg/panel |
| Brightness | ＞1200 nits |
| Color Temperature | 3000-12000K |
| Viewing Angle | H-140°/ V-140° |
| Refresh Rate | 960-2880Hz |
| Frame Frenquency | 60Hz |
| Grey Level | 4096-16384 |
| Number of Color | 1 billion |
| Input Maximum Power | 250 W/panel |
| Input Voltage | AC220±10%, AC110 ±10% |
| Input Frequency | 50-60Hz |
| External Interface | S-video, VGA, DVI, SDI, CVBS, YPrPb, HDMI, etc |
| IP Rating | IP43 |
FAQ
Q1. Can I have a sample order for this products?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q2. What about the lead time?
A:Production time needs about 15 working days for order quantity more than 6 sqm.
Q3. Do you have any MOQ limit for LED screen order?
A: Low MOQ, 1pc for sample checking is available, and Normal order's MOQ is6 pcs cabinet
Q4. How do you ship the goods and how long does it take to arrive?
A: By express is the fastest but most expensive. By airplan also need about 7 days , middle cost.By sea is the most economic but will take 20-30 days transit time. Small order Express is a good solution, Big order always by sea.
Q5. How to proceed an order for LED screen?
A: Firstly let us know your requirements or application.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms the samples and places deposit for formal order.
Fourthly We arrange the production.
Q6. Is it OK to print my logo on led light product?
A: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.
Q7: Do you offer guarantee for the products?
A: Yes, we offer 2 years warranty to our products.
