1920 - 3840Hz PH3mm P5 Super Slim Led Display 12000K For Clubs , Bars

Basic Properties
Place of Origin: China
Certification: CE, CCC, FCC, ROSH, ISO9001
Trading Properties
Minimum Order Quantity: 1pcs
Price: USD 400-1999 per sqm
Payment Terms: T/T, Western Union
Supply Ability: 1300 square meters per month
Tags

p5 led display

ultra thin led screen

led stage screen rental
Product Summary
1920 - 3840Hz PH3mm P5 Super Slim Led Display 12000K For Clubs , Bars Application: LED video technology integrate with stage design; Ceiling for clubs, bars, hotels, and super malls; Concert's background stage lighting; Architectures decoration; Specifications: Pixel Pitch 3mm Pixel Package SMD2121 LED Configuration 1R1G1B Pixel Density 111111 Pixels/㎡ Module Size 240mm x 240mm Module Resolution 80 x 80 dots Suggested Cabinet Size 480mm x 480mm x 64mm Cabinet Resolution 160 x

Product Details

Highlight:

p5 led display

,

led stage screen rental
Encapsulation: SMD2121
Color: Full Color
Cabinet: Die-casting Aluminum Alloy
Cabinet Size: 480x480mm
View Angle: 140°(Horizontal )/140°(Vertical )
LED Lifespan: 100,000 Hours
Viewing Distance: 3-90 Meters
Product Description

1920 - 3840Hz PH3mm P5 Super Slim Led Display 12000K For Clubs , Bars



Application:

LED video technology integrate with stage design;

Ceiling for clubs, bars, hotels, and super malls;

Concert's background stage lighting;

Architectures decoration;



Specifications:



Pixel Pitch 3mm
Pixel Package SMD2121
LED Configuration 1R1G1B
Pixel Density 111111 Pixels/㎡
Module Size 240mm x 240mm
Module Resolution 80 x 80 dots
Suggested Cabinet Size 480mm x 480mm x 64mm
Cabinet Resolution 160 x 160 dots
Cabinet Material Die-casting Aluminum Alloy
Cabinet Weight 6.8 kg/panel
Brightness 1000-2000 nits
Color Temperature 3000-12000K
Viewing Angle H-140°/ V-140°
Driving Mode 1/16
Refresh Rate 1920-3840Hz
Frame Frenquency 60Hz
Grey Level 4096-16384
Number of Color 1 billion
Input Maximum Power 1200 W/㎡
Input Voltage AC220±10%, AC110 ±10%
Input Frequency 50-60Hz
External Interface S-video, VGA, DVI, SDI, CVBS, YPrPb, HDMI, etc
IP Rating IP43


Features:



1. seamless assembling, less than 1mm.



2. High-definition visual effect.



3. High thermal conductivity Alloy cabinet, better heat dissipation



4. Fan-free design, energy saving, more stable,



5. 140〫 degree wilde view angle



6. Power, signal indicators in the power box.



7. Approved by RoHS certification, Lead-free, enviromental design



8. Ergonomic handle design, convenient handling



9. High performance and adjustable side lock.



10. International standards air plug on Power connectors, easy, fast and safe.



11. Receiving card to card with LAN cable, simple, less failure rate
