High Brightness 32x32 Led Matrix Display 160000 Pixels/㎡ 1R1G1B Rental Led Screen
Basic Properties
Place of Origin:
China
Certification:
CE, CCC, FCC, ROSH, ISO9001
Trading Properties
Minimum Order Quantity:
1pcs
Price:
USD 400-1999 per sqm
Payment Terms:
T/T, Western Union
Supply Ability:
1300 square meters per month
Product Summary
High Brightness 32x32 Led Matrix Display 160000 Pixels/㎡ 1R1G1B Rental Led Screen Features: 1. seamless assembling, less than 1mm. 2. High-definition visual effect. 3. High thermal conductivity Alloy cabinet, better heat dissipation 4. Fan-free design, energy saving, more stable, 5. 140〫 degree wilde view angle 6. Power, signal indicators in the power box. 7. Approved by RoHS certification, Lead-free, enviromental design 8. Ergonomic handle design, convenient handling
Product Details
Highlight:
led screen manufacturer
,led video wall panels
Pixel Pitch:
Small Pixel Pitch PH2.5mm
Encapsulation:
SMD2121
Color:
Full Color
Cabinet:
Die-casting Aluminum Alloy
Cabinet Size:
400x300mm
View Angle:
140°(Horizontal )/140°(Vertical )
LED Lifespan:
100,000 Hours
Module Resolution:
32*32ixel
Product Description
High Brightness 32x32 Led Matrix Display 160000 Pixels/㎡ 1R1G1B Rental Led Screen
Features:
1. seamless assembling, less than 1mm.
2. High-definition visual effect.
3. High thermal conductivity Alloy cabinet, better heat dissipation
4. Fan-free design, energy saving, more stable,
5. 140〫 degree wilde view angle
6. Power, signal indicators in the power box.
7. Approved by RoHS certification, Lead-free, enviromental design
8. Ergonomic handle design, convenient handling
Specification
|
Pixel pitch
|
6mm
|
|
Pixel configuration
|
1R1G1B
|
|
LED type
|
3-in-1 black SMD2727
|
|
Module size
|
W192*H192mm
|
|
Module weight
|
480g
|
|
Module quantity
|
27 pcs/m²
|
|
Min. Viewing Distance
|
6m
|
|
Brightness
|
≥5000cd/m²
|
|
Viewing Angle
|
H≥120° V≥120°
|
|
Driving Mode
|
1/8scan constant current driving
|
|
Interface
|
HUB75
|
|
Input voltage
|
4.8-5.5VDC
|
|
Max. Power Consumption
|
606w/m²
|
|
Avg. Power Consumption
|
243 w/m²
|
|
Max. Current
|
6.2A
|
|
Frame rate
|
60 frames/s
|
|
Refresh Rate
|
≥1920Hz
|
|
Defective Dots Rate
|
<0.0001 (LED display line standard: ≤ 0.0003)
|
|
Decay Rate
|
≤5%/year
|
|
Brightness Conformity
|
>95%
|
|
MTBF
|
≥10000 hours
|
|
Lifespan
|
≥50000 hours
|
|
Protective function
|
Over-heat/Over-load /Power-down /Power-leakage/Lightning
|
|
|
-protection etc.
|
|
Operating Temperature
|
-20℃~+50℃
|
|
Operating Humidity
|
10-85% no condensation
|
|
Storage Temperature
|
-30℃~+60℃
|
|
Storage Humidity
|
10-85% no condensation
|
|
control system parameter
|
|
|
Color temperature
|
Adjustable by sofeware.
|
|
brightness level
|
256 levels,automatic or manual adjustment
|
|
control way
|
computer,real-time,offline,wireless,internet etc.
|
|
communication distance
|
cat5 UTP 100 meters,max.130 meters;or optical fiber
|
|
packing
|
High Quality P5 P5.93 P8 P10 outdoor large signs advertising full color large led display
|
|
carton
|
40pcs/carton,size:L580*W370*H410mm,weight:18.3kgs
|
