480x480 P5 Super Slim Led Display Die casting Aluminum Alloy Cabinet
480x480 P5 Super Slim Led Display Die casting Aluminum Alloy Cabinet Specifications: Pixel Pitch 2.5mm Pixel Package SMD2121 LED Configuration 1R1G1B Pixel Density 160000 Pixels/㎡ Module Size 160mm x 160mm Module Resolution 64 x 64 dots Suggested Cabinet Size 480mm x 480mm x 64mm Cabinet Resolution ...
Certification:
CE, CCC, FCC, ROSH, ISO9001
Place of Origin:
China
Minimum Order Quantity:
1pcs
Price:
USD 400-1999 per sqm
Supply Ability:
1300 square meters per month
Delivery Time:
within 15 to 20 working days after receiving deposit
Payment Terms:
T/T, Western Union
Standard Packaging:
Flight case or wooden case
Product Description
480x480 P5 Super Slim Led Display Die casting Aluminum Alloy Cabinet
Specifications:
| Pixel Pitch | 2.5mm |
| Pixel Package | SMD2121 |
| LED Configuration | 1R1G1B |
| Pixel Density | 160000 Pixels/㎡ |
| Module Size | 160mm x 160mm |
| Module Resolution | 64 x 64 dots |
| Suggested Cabinet Size | 480mm x 480mm x 64mm |
| Cabinet Resolution | 192 x 192 dots |
| Cabinet Material | Die-casting Aluminum Alloy |
| Cabinet Weight | 7.1 kg/panel |
| Brightness | 1000-2000 nits |
| Color Temperature | 3000-12000K |
| Viewing Angle | H-140°/ V-140° |
| Driving Mode | 1/32 |
| Refresh Rate | 1920-3840Hz |
| Frame Frenquency | 60Hz |
| Grey Level | 4096-16384 |
| Number of Color | 1 billion |
| Input Maximum Power | 1300 W/㎡ |
| Input Voltage | AC220±10%, AC110 ±10% |
| Input Frequency | 50-60Hz |
| External Interface | S-video, VGA, DVI, SDI, CVBS, YPrPb, HDMI, etc |
| IP Rating | IP43 |
Features:
1. seamless assembling, less than 1mm.
2. High-definition visual effect.
3. High thermal conductivity Alloy cabinet, better heat dissipation
4. Fan-free design, energy saving, more stable,
5. 140〫 degree wilde view angle
1. High,SMD black ligth +black mask,showing a high contrast,better visual effects.
2. High -end S--PWM IC driver,high refresh,high grayscale,high brightness,no blur.
3. Single point brightness,color correction,color consistency is preferrred.
4. Board to board connector design,no link cable,improve stability,easy installation and
disassembly maintenance.
5. Easy front maintenance,a screw,a tool to complete.
Product Details
Highlight:
p5 led display
,led stage screen rental
Pixel Pitch:
PH2.5mm
Encapsulation:
SMD2121
Color:
Full Color
Cabinet:
Die-casting Aluminum Alloy
Cabinet Size:
480x480mm
View Angle:
140°(Horizontal )/140°(Vertical )
LED Lifespan:
100,000 Hours
Working Voltage:
AC 220V/110V S±15% 50-60 HZ
Viewing Distance:
2-75 Meters
