Outdoor Rgb P10 Led Display Module Full Color Smd Led Screen 160*160mm
Outdoor Rgb P10 Led Display Module Full Color Smd Led Screen 160*160mm
Designed to withstand adverse weather conditions and to astound audiences and make them enjoy
flickering-free live videos in sharp and brilliant images. Outdoor display solutions present the
exceptional performance in crowded outdoor settings where are clearly visible, even the most complex
advertising images and logos are precisely rendered, making it the display technology of choice for all
brands.
Product Features
- Superb brightness, color uniformity and reproduction. Brightness variances within +/- 2.5%;
- Extremely weather-proof, adapt to different kinds of environment;
- Support automatic fault detection;
- Refresh rate up to 4,200Hz, completely flickering-free for live videos;
- Proprietary image processing produces sharp, brilliant images – unmatched by industry competition;
- 6000 : 1 contrast ratio tempers screen brightness into sharp, focused images whether up close or far away;
- 6,6000 nits guarantees the screen stays brighter longer, providing 100,000 hours of continuous use.
- Superior, steady, bright image displays, demonstrated in Malaysia, Iran, Mexico, Singapore and Australia.
Technical Parameters:
The main parameter
|
P10 Full Color Display |
|
|
Physical Pixel Pitch |
10mm |
|
Module Size |
160*160mm |
|
Pixel Density |
10000/㎡ |
|
Pixel Configuration |
1R1G1B DIP346 |
|
Best Viewing Distance |
10m |
|
View Angle(Horizontal) |
110° |
|
Brightness |
≥7000cd/㎡ |
|
Driving Method |
1/4 Constant Driving |
|
Control Mode |
Real Pixel |
|
Cabinet Size |
640*480mm |
|
Cabinet Resolution |
64*48 |
|
Cabinet Weight |
32kg |
|
Maximum Power Consumption |
920W/㎡ |
|
Operating Voltage |
220±10% or 110±10% |
