8mm 1R1G1B LED Screen 32*16 Epistar Advertising Led Display Panel
|
8mm 1R1G1B LED Screen 32*16 Epistar Advertising Led Display Panel
| MOQ: | 1pcs |
| Price: | USD 400-1999 per sqm |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 1300 square meters per month |
led video screen
,advertising led display screen
8mm 1R1G1B LED Screen 32*16 Epistar Advertising Led Display Panel
1, Curve LED display with angle;
2, Large viewing angle;
3, LED Chips: Epistar
4. LED Source: DIP 346;
5. Module: 320mm x 160mm;
6. IP65, waterproof
Features:
(1) Brightness adjustable
(2) High Refresh Rate reach to 3000Hz or more
(3) Long lifespan and stable quality
(4) Working under the temperature -30C to +75C
(5) Save 35% power than normal screens
Application:
advertising LED display, shopping mall LED display for logo showing , bank & stock exchange LED display for rates showing , train & bus station , airport , telecommunication LED screen system for information showing and instruction , Stage performances and so on.
Function:
- Excellent visual effect, clear and exquisite
- Good flatness.
- Easy to clean, welding spots inoxidizable.
- Closer look available, better effects without glare and mosaic.
- Good viewing angle.
- Easy to assembly, install and transport with simple packing and convenient use.
- Vivid mixed colors.
- No color cast when look from different angles.
- Excellent heat-sinking, high stability, no scrapped lamp.
Specifications:
|
Product type |
P8 |
|
Pixel pitch |
8mm |
|
Pixel constitution |
1R1G1B |
|
LED package mode |
SMD3528/SMD3535 |
|
Pixel density |
15625dots/㎡ |
|
Scan mode |
4 |
|
Brightness |
5000 cd/㎡ / 5500cd/㎡ |
|
Module resolution |
32*16 |
|
Module size |
256*128mm |
|
Max. consumption |
1000W/㎡ |
|
Ave. consumption |
400W/㎡ |
|
Viewing angle |
Horizontal 120°/Vertical 100° |
|
Cabinet |
Customized (size, color, design etc.) |
|
Control Method |
Synchronous |
|
Frame frequency |
≧ 60Hz |
|
Refresh Rate |
≧ 400Hz,Max. 2000Hz |
|
Grey level |
≧ 4K grade |
|
Brightness adjustment |
Manual or Auto 100 grade |
|
Working temperature |
-10 OC — +45 OC |
|
Working voltage |
AC220V±10%；50Hz(AC110V optional) |
|
Video interface |
VGA,DVI,CVBS,Y/C,YPbPr,SDI/HDSDI,HDMI etc |
|
Communication distance |
Network cable≦100m; Multimode Fiber≦500m; Single mode Fiber≦10km |
|
Average fault-free |
5000hours |
|
Life span |
100000hours |
|
Defect ratio |
≦0.1‰ |
|
control system |
DVI display card + full color controller card |
Competitive Advantage:
1) Price Advantage: Best competitive price of the market.
2) Performance Advantage: Best brightness, High refresh rate, high consistency, Big viewing angle...
3) Quality advantage: From material to finished product, from design to produce, we control all steps, that's the guarantee of the quality and reliability.
4) Service advantage: with professional service team for 24 hours service!
